Võlli läbimõõt 60 mm
Rullide läbimõõt 215 mm
Painutamine kiirus 4 m / min
Motor 1,5 kW 400 V
Sügavus 1000 mm
Laius 1400 mm
Kõrgus 1650 mm
kaitseklass IP23
Kaal 950kg
Bending performances profile type standard
Square material dimensions [1]50 mm
Square material min. bending Ø [1]800 mm
Square material dimensions [2]20 mm
Square material min. bending Ø [2]400 mm
Flat material light axis dimensions bending Ø [1]120x25 mm
Flat material light axis min. bending Ø [1]600 mm
Flat material light axis dimensions bending Ø [2]50x10 mm
Flat material light axis min. bending Ø [2]400 mm
Flat material heavy axis dimensions bending Ø [1]80x20 mm
Flat material heavy axis min. bending Ø [1]1200 mm
Flat material heavy axis dimensions bending Ø [2]40x10 mm
Flat material heavy axis min. bending Ø [2]400 mm
UPN profile top rib dimensions [1]80x9 mm
T profile top rib min. bending Ø [1]1000 mm
UPN profile top rib dimensions [2]40x5 mm
T profile top rib min. bending Ø [2]400 mm
Explanation for T profile rib aboveAdditional spacers may be required
UPN profile outside rib dimensions [1]80x9 mm
T profile outside rib min. bending Ø [1]1000 mm
UPN profile outside rib dimensions [2]40x5 mm
T profile outside rib min. bending Ø [2]400 mm
UPN profile inside rib dimensions [1]80x9 mm
T profile inside rib min. bending Ø [1]1200 mm
UPN profile inside rib dimensions [2]40x5 mm
T profile inside rib min. bending Ø [2]500 mm
UPN profile outside leg dimensions [1]UPN 120
UPN profile outside leg min. bending Ø [1]800 mm
UPN profile outside leg dimensions [2]UPN 60
UPN profile outside leg min. bending Ø [2]500 mm
UPN profile inside leg dimensions [1]UPN 120
UPN profile inside leg min. bending Ø [1]1200 mm
UPN profile inside leg dimensions [2]UPN 60
Inside leg min. bending Ø [2]600 mm
Explanations for bending performance, profile type standardThe performance data apply to material with a max. Yield strength of 24kg / mm². Bending power at VA: factor 0.7
