Product info
Minimum working width (finished section) 25mm
Maximum working width (finished section) 230mm
Minimum working height (finished section) 6mm / 10mm
Maximum working height (finished section) 120mm
Minimum length of single component - comp.5 630mm
Variable feed speed with inverter 5 ÷ 25m/min
Feed motor power 3 kW (4 Hp)
Planer spindle motor power 4 kW (5,5 Hp)
Vertical spindles motor power (single) 5,5 kW (7,5 Hp)
Top horizontal spindle motor power 4 kW (5,5 Hp)
Bottom horizontal spindle motor power-Comp.5 4 kW (5,5 Hp)
Spindles speed 6.000 rpm
Spindles diameter 40mm
Vertical spindles length 140mm
Horizontal spindles length 250mm
Axial adjustment of vertical spindles with respect to the
worktable 40mm
Axial adjustment of horizontal spindles with respect to the
right fence 40mm
Min./max. tool diameter on surface planer 120 - 140mm
Min./max. tool diameter on vertical spindles 100 - 180mm
Max. profiling capacity on vertical spindles 40mm
Min./max. tool diameter on top horizontal spindle 125mm
Min./max. tool diameter on 2nd bottom horizontal spindles 100 - 180mm
Profiling capacity with tool 180mm on 2nd bottom horizontal
spindles 15mm
Feed rollers diameter 140mm
Infeed table length 2.000mm
Rapid adjustment of infeed table and fence 10mm
No. 2 feed rollers 140x25mm for each feed hub STD
Manual pump for table lubrication STD
Manual centralised lubrication STD
