Product info
AXES
Max. panel length mm 3.050
Min. panel length mm 200
Max. panel width mm 900
Min. panel width mm 80
Max. panel thickness mm 60
Min. panel thickness mm 10
Max. X axis speed m/min 40
Max. Y axis speed m/min 40
DRILLING HEAD
Vertical spindles no. 8 (5X-3Y)
Horizontal spindles no. 6 (2+2X-2Y)
Rotating spindles motor power kW (Hp) 2,2 (3)
Spindle speed rpm 4.200
Fixed integrated disc cutter
(direction) X
Max. diameter of disc cutter mm 125
Disc cutter rotating speed rpm 5.500
ELECTROSPINDLE
Motor power KW (Hp) 5,5
Min./Max. speed rpm 1.000/18.000
Tool changer manual
Max tool diameter mm 20
INSTALLATION
Compressed air consumption Nl/min 50
Extraction air consumption m3/h
1900+540+1200 (+540 vers.
R)
Exhaust air speed m/sec 30
Installed motor power kVA 15,2 (20,7 vers. R)
Exhaust outlet diameter mm 150+120+80 (+80 vers R)
