Product info
For a wide range of applications
Suitable for general assembly and straightening work as well as workpiece testing
Height-adjustable work table
Manual control of the piston
Hydraulic unit with two speeds
Pressing pressure readable via pressure gauge
Pressure force 60t
Piston stroke 380mm
Press speed 2,87mm/s
Return speed 9,5mm/s
Pressure regulation Manually with a knob
Length (product) approx. 1300mm
Width/depth (product) approx. 650mm
Height (product) approx. 2100mm
Net weight approx. 1250kg
Clear height max. 775mm
Drive motor output 2,2kW
Supply voltage 400V
Mains frequency 50Hz
