2134,00 €
1
Available to order. The delivery time will be confirmed after the order is placed. If it doesn’t work for you, you can cancel.
Installment: 57,65 € per month.
Pay Later
Explore installment payment options. You can choose a suitable solution in the shopping cart.
Service provided by
_EE.png "ESTO JM")
Pay in three equal monthly installments, starting from next month. No fees or interest.
| Date | Payment |
|---|---|
| 05.05.2026 | 711,33 € |
| 05.06.2026 | 711,33 € |
| 05.07.2026 | 711,33 € |
Service provided by
.png "ESTO 3 equal parts")
Pay next month for 25th of the month. No fees or interest.
| Date | Payment |
|---|---|
| 25.05.2026 | 2134,00 € |
Service provided by
Purchasing this product you earn 71 bonus nuts.
Product info
Work areas:
Max. height125mm
Max. width550mm
Swing diameter above machine bed250mm
Bed width135mm
Speed range:
Number of gears6
Speed range125 – 2000min¯¹
Spindle:
Spindle chuckcylindrical Ø 52mm
Spindle bore/rod passage diameter21mm
Spindle coneMT 3
Tool holder max. chuck height14mm
Tailstock:
Tailstock chuckMT 2
Tailstock quill stroke70mm
Pitches:
Metric pitch0.4 – 3.5mm/rev
Number of metric pitches14
Imperial pitch44 – 10Threads/1"
Number of imperial pitches12
Travel:
Travel X axis75mm
Travel Z axis120mm
Electric Data:
Drive motor output0.75kW
Supply voltage400V
Phase(s)3Ph
Current typeAC
Mains frequency50Hz
Dimensions and weights:
Length (product) approx.1090mm
Width/depth (product) approx.594mm
Height (product) approx.484mm
Net weight approx.127kg
