2756,00 €
Factory order. Estimated delivery 02.09.2026
Installment: 74,34 € per month.
Purchasing this product you earn 150 bonus nuts. Look closer
Product info
Voltage 230 V
Drilling performance steel (S235JR)20mm
Max. size milling head52mm
Max. size shaft milling cutter20mm
Continuous drilling performance steel (S235JR)16mm
Horizontal milling table length700mm
Horizontal milling table width180mm
Max. clearance vertical spindle - horizontal milling table 370mm
Horizontal milling table max. load bearing capacity40kg
Travel X axis manual480mm
Travel Y axis manual175mm
Travel Z axis manual210mm
Vertical spindle reach170mm
Vertical spindle spindle chuckBT 20
Vertical spindle swivel range milling cutter head Z - X plane 90°
Vertical spindle speed range90 – 3000min¯¹
Vertical spindle quill diameter60mm
Vertical spindle quill stroke45mm
Vertical spindle speed controlelectronically adjustable
Verticle spindle drive motor output S6-30 % operation0.93kW
- Weight 116 kg
- Weight with package 143 kg
- Dimensions (with package) 92 x 77 x 71 cm
- Sales unit pcs
- GTIN / EAN 4030635032554
- Manufacturer part number 3338135
