Fixed stairs w/o platform 12 steps 2211

Fixed stairs without platform, step angle 45° * Step width optionally 600, 800 or 1,000 mm. * For access ways to machines or machinery systems, a step width of 600 mm is only permitted in exceptional cases. * Aluminium profile steps 250 mm deep, alternatively aluminium or steel grating steps 240 mm deep at additional cost. * As standard with one handrail, mounted on the left, second handrail available at extra cost. * For access paths to machines or machinery systems, handrails on both sides are mandatory if the distance to the object is larger than 120 mm. * Standard design with 2 wall mounting brackets at top and floor brackets at bottom, on request at top with suspension * hook or bearing bracket at additional cost. * Intermediate sizes at price of next highest number of steps. * Permissible load of step 150 kg, permissible load total 150 kg/m² (max. 300 kg). * For use only by one person. * Not available on stock, production on order, therefore, no exchange possible. * Shipped in subassemblies pre-assembled in the factory. Measurments Step width600mm Max. standing height2.52m Overhang 2.74m Weight(approx)47kg Number of steps 12 Step angle 45° Step depth250mm
