Product info
Technical data
Weight 1000 kg
Lifting capacity 5000 kg
Lift height 1910 mm
Platform initial height 110 mm
Height 2850 mm
Width 3620 mm
Lifting arms lenght: 890-1800mm
Lifting time ≤ 45 s
Descent time ~ 45 s
Power supply 3/N/PE-380V, 50Hz,16A
Power 3 kW
Hydraulic oil 12 L
Working temperature 5° - 40° C
Working humidity 30 - 95%
Noise < 70db
Storage temperature -25° - 55°
Foundation depth w/o floor covering 300 mm
Concrete strength B25
Fuse protection 3C16 A
Size of the concrete block 1,5m x 4m x 0,3m
The lift should be fixed on a smooth and solid concrete ground with its strength more than 210 kg/cm², tolerance of fatness less than 5mm and minimum thickness of 300mm. In addition, newly built concrete ground must undergo more than 28 days’ cure and reinforcement.
Magneti Marelli 2-year warranty
Magneti Marelli provides a 2-year company warranty for its products. The 2-year company warranty requires:
-
the user to carry out periodic maintenance activities and to use the device in accordance with the user manual,
-
after the purchase of the device, an annual inspection and maintenance of the device performed by the Stokker service team.
-
- Weight 1400 kg
- Weight with package 1400 kg
- Dimensions (with package) 57 x 305 x 76 cm
- Sales unit set
- GTIN / EAN 0079350136905
- Manufacturer part number 007935013690
